Product Description

Summarize:

3RP series high viscosity vane pump is a kind of multi-purpose double-direction volumetric pump produced by our company with the introduction of advanced technology from Germany, and the professional manufacturing technology and manufacturing precision of the product are close to the same kind of product from Germany. The product can effectively transport viscosity up to 30 × 10⁵cSt of high viscosity corrosive media, can be applied to daily chemical, building materials, pharmaceutical, petroleum, food and beverage processing industries. In addition, the product has a stable flow and pressure output to meet the needs of different working conditions.

Product Details:

3RP series food grade lobe pump is mainly composed of rotor, shaft seal, gear box, a pair of synchronous meshing of the active gear, driving the rotor to transport media. The machine relies on two synchronously rotating rotors, the rotor in the process of rotation at the inlet to generate suction, so that the conveyed material will be inhaled, the two rotors will rotor cavity into different spaces, and then run in turn to transport the media to the discharge port, and so on and so forth, the conveyed material will be transported out continuously. In addition, the pump utilizes a high-strength cast iron gearbox, helical gears and heavy-duty bearings to ensure long-term pump operation.

Application:

1. Pharmaceuticals: Pills, extracts, emulsions, creams.
2. Chemicals: Fats, solvents, resins and polymers, dyes.
3. Dairy Products: Yoghurt, cream, ice cream, cheese and whey.
4. Cosmetics: Creams and lotions, hairsprays, hair dyes, essential oils.
5. Beverages: Beer, wort, yeast, soft drinks, fruit juice concentrates, fruit drinks.
6. Confectionery: Syrups, cream fillings, purees, fruit fillings, puddings, jams, jellies, chocolates.
7. Foodstuffs: ketchup, vegetable pastes, sauces, sweeteners, yeast pastes, salads, meat emulsions, cooking oils.

Advantage:

1. The viscosity of the transportable medium is ≤2000000 cp, and the pump can transfer slurry containing 70% solids.
2. There is a certain gap between rotor and rotor, no friction coefficient, so pump has a long service life time.
3. It is easy to install and disassemble,and it is convenient to maintain, clean .There is less wearing parts.
4. With VFD, the flow can be adjusted at will, and the pump can be used as a general metering pump.
5. There are two types of inlet and outlet connection, incuding flange joint, threaded connection.
6. It can transport gas, liquid and solid three-phase mixture materials.

Performance Data:

Model	Flow		Pressure	Speed	Power	Pipe size
	L/100r	m3/h	Mpa	rpm	kw	DN
3RP-6	6	1.8	0-1.2	10-500	0.75	20/25
3RP-9	9	2.6	0-0.6	10-500	1.1	25/32
3RP-18	18	4.3	0-0.2	10-400	1.5	32/50
3RP-36	36	8.5	0-0.6	10-400	2.2	50/65
3RP-60	60	14.3	0-0.6	10-400	4	65/80
3RP-105	105	25	0-1.2	10-400	11	80/100
3RP-150	125/250	35	0-0.6	10-400	18.5	100/125
3RP-250	250	45	0-0.6	10-400	22	125/150
