Wear Resistant 3RP Series Horizontal High Viscosity Lobe Pump

Email: sales@shenghuipump.com

Fax: +86-0317-8109918

Tel: +86-0317- 8109958 +86-0317-8109968

Whatsapp & Wechat & Mobile:
+86-15227503158

Add: South 4 # Road, Industrial Park, Botou City , 062150, Hebei Province,China

ZX Self-Priming Centrifugal Pump

ISW Series Horizontal Inline Centrifugal Pump

ISW Series Inline Centrifugal Pump

G Series Sludge Screw Pump

Automatic Mineral Water Water Bottle Filling Machine

Mineral Water Bottle Filling Machine

LPG Gas Transfer Pump for Sale

Product Description

Summarize:

3RP series rotary lobe pump belongs to one kind of volumetric pump, which is specially used to deal with viscosity, high concentration and other poor fluidity materials, also can transport gas, liquid, solid phase mixture materials. It can be applied to food, beverage, pharmaceutical, chemical, daily chemical, petroleum and other media hygiene requirements of strict industry. In addition, it has the advantages of low running noise, long service life, wide application, and small footprint.

Product Details:

3RP series rotary lobe pump is mainly composed of rotor, shaft seal, gear box, a pair of synchronous meshing of the active gear, driving the rotor to transport media. Adopted is the gear transmission mode, the main shaft and auxiliary shaft drive the rotor synchronous reverse rotation, so that the pump volume changes, thus forming a higher vacuum and discharge pressure, so especially suitable for sanitary media and highly corrosive high viscosity media. In addition, the pump utilizes a high-strength cast iron gearbox, helical gears and heavy-duty bearings to ensure long-term pump operation.

Application:

1. Food Industry: Including sour milk, whipped cream, ice cream, cheese block, whey, beer, wort, yeast, jam, syrup, juice, pudding, ketchup, sesame sauce, condiments, edible oil, etc.
2. Daily Chemical Industry: Such gel, face wash, hand soap, shower gel, laundry detergent, skin care products, toothpaste, detergent, shampoo, shoe polish, cosmetics, soap, etc.
3. Chemical industry: Fats, solvents, polymers, paints, pigments, dyes, lubricants, greases, petroleum agents, adhesives, plastics, glass fiber reinforced plastic, leather and so on.
4. Construction Industry: Interior and exterior wall coatings, anticorrosive materials, ceramic coatings, paints and coatings, ceramic glaze, etc.
5. Pharmaceutical Industry: For various emulsifiers, syrups, nutrient solutions, cream pharmaceuticals, biological products, fish pollen, etc.
6. Other Industries: Plastic industry, textile industry, paper industry, biochemical industry, etc.

Advantage:

1. Low noise: Smooth running and low noise, creating a quiet working environment.
2. High efficiency and energy saving: With high working efficiency, it can effectively reduce energy consumption.
3. Low failure rate: With the features of simple structure, stable operation, low failure rate, reducing maintenance costs and downtime.
4. Reliable sealing: The use of high-quality sealing materials and advanced sealing technology ensures the sealing of the pump when conveying various media.

Performance Data:

Model	Flow		Discharge Pressure (Mpa)	Rev (rpm)	Motor Power (kw)	Inlet/Outlet (mm)
Model	L/100r	m3/h	Discharge Pressure (Mpa)	Rev (rpm)	Motor Power (kw)	Inlet/Outlet (mm)
3RP-25	6	≤1.8	0-1.0	10-400	0.75	25
3RP-32	9	≤2.7			1.1	32
3RP-40	18	≤4.3			1.5	40
3RP-50	36	≤8.6			2.2	50
3RP-65	60	≤14.4			4	65
3RP-80	105	≤25.2			11	80
3RP-100A	125	≤30			15	100
3RP-100	150	≤36			18.5	100
3RP-125	250	≤60			22	125
