Product Description

Summarize:

3RP series chemical lobe pump is a positive displacement pump that can convey suspension, corrosive media and suspensions suitable for soft solid particles, conveying media with temperatures ranging from -30 to 180 ℃ and viscosities ranging from 30 cst to 1.0×105 cst. To ensure the corrosion resistance and hygiene of the liquids, the internal parts of this machine that come into contact with the media are all made of durable stainless steel. As a result, it is used extensively in food, beverage, pharmaceutical, chemical, daily chemical, petroleum and other processing industries.

Product Details:

3RP series chemical lobe pump is mainly composed of rotor, shaft seal, gear box, a pair of synchronous meshing of the active gear, driving the rotor to transport media. It consists of two synchronized rotors/cams driven by a pair of synchronized gears in the gear box. Driven by the main shaft and the secondary shaft, the two rotors rotate in opposite directions, thus changing the volume of the pump and increasing the vacuum and discharge pressure. In addition, the pump utilizes a high-strength cast iron gearbox, helical gears and heavy-duty bearings to ensure long-term pump operation.

Application:

1. Chemical industry: It can convey polyester, polypropylene, synthetic fiber, functional dimension, etc., as well as all kinds of dyestuffs, pigments, adhesives, silicone oil, chemical auxiliaries, all kinds of colloidal materials, etc.
2. Food industry: It can convey chocolate, condensed milk, yogurt, honey, syrup, tomato juice, concentrated fruit juice, jam, ice cream, jelly, condiment, wine lees, flour slurry and so on.
3. Daily chemical industry: Suitable for conveying laundry detergent, shower gel, skin cream, shampoo, hand soap, toothpaste, soap, daily chemical raw materials and so on.
4. Pharmaceutical industry: This machine can convey all kinds of ointments, syrups, health care products, pharmaceuticals, etc.

Feature:

1. It can convey medium viscosity ≤ 2,000,000cp, can convey slurry with 70% solid content.
2. Convenient installation and disassembly, easy maintenance and cleaning, few wearing parts.
3. There is a certain clearance between the rotor and the rotor, no friction coefficient, long service life.
4. With the features of high efficiency and energy saving, smooth conveying, low failure rate, sealing without leakage, low noise.
5. This machine can be equipped with frequency converter, the flow rate can be adjusted arbitrarily, can be used as a general-purpose metering pump.

Performance Data:

Model	Flow		Discharge Pressure (Mpa)	Rev (rpm)	Motor Power (kw)	Inlet/outlet (mm)
Model	L/100r	m3/h	Discharge Pressure (Mpa)	Rev (rpm)	Motor Power (kw)	Inlet/outlet (mm)
3RP-25	6	≤1.8	0-1.0	10-400	0.75	25
3RP-32	9	≤2.7			1.1	32
3RP-40	18	≤4.3			1.5	40
3RP-50	36	≤8.6			2.2	50
3RP-65	60	≤14.4			4	65
3RP-80	105	≤25.2			11	80
3RP-100A	125	≤30			15	100
3RP-100	150	≤36			18.5	100
3RP-125	250	≤60			22	125
