WCB Series Gear Oil Pump
WCB Series Gear Oil Pump
WCB Stainless Steel Gear Pump
WCB series stainless steel gear pump is a portable energy-saving oil pump with features of small size, lightweight, high performance, reasonable use, stable operation and compact structure. It is suitable for conveying lubricating oil or other liquids with properties similar to lubricating oil without solid particles and fibers without corrosion. In addition, the machine is equipped with a handle design, so it is easy for the user to move in the hand.
Head Lift: 0.3Mpa
Power: 0.37-0.75kW
Flow Rate: 30-75L/min
Product Description
Summarize:

WCB series stainless steel gear pump belongs to low pressure miniature portable energy-saving oil transfer pump, which is suitable for handling lubricating oil or other liquids with properties similar to lubricating oil that do not contain solid particles and fibers, are non-corrosive, and have a temperature of not more than 80℃. Its gears are made of alloy steel and adopt special hot processing technology, the surface hardness can be above HRC60, so it is characterized by long service life and strong wear resistance.

Product Details:
WCB series stainless steel gear pump is a portable energy-saving oil pump, mainly composed of gears, shafts, pump body, shaft end seals, etc. The gears are heat-treated with high hardness and strength, and are installed with replaceable bushings to run. The gears are heat-treated for high hardness and strength, and are installed together with the shaft to run in a replaceable shaft sleeve.


Application:
1. In the industrial field, it can be used as lubrication oil pump
2. It is used as a fuel pump to transfer, pressurize and inject in the fuel system.
3. For fuel delivery system, this machine can also be used as a transfer booster pump.
4. The machine can be used as a hydraulic pump in a hydraulic transmission system to provide hydraulic power.
Feature:

1. It adopts a compact structure, is easy to use and maintain, and has good self-priming ability, eliminating the need to add liquid before each pump start-up.
2. This pump is equipped with a safety valve that automatically returns oil in the event of a blockage or overpressure, thereby protecting the motor and pipeline.
3. It can be automatically lubricated, with lubrication automatically performed by the conveyed liquid, eliminating the need to add other lubricants during daily operation.

Performance Data:
Type Flow L/min Conveying Height   m Weight   kg Driving Power       w Use Power v Material
WCB30 30 30 17 370 220 Csat iron
WCB50 50 30 19 550 220 Csat iron
WCB75 75 30 21 750 220 Csat iron
WCB30P 30 30 17 370 220 Stainless steel
WCB50P 50 30 19 550 220 Stainless steel
WCB75P 75 30 21 750 220 Stainless steel
