2CG High Temperature Gear Pump
It is suitable for conveying non-solid particles and fibers, non-corrosive high temperature liquid, the medium temperature can reach 250oC, and the viscosity is 5-1500cst. It is used for conveying and pressurizing media such as residual oil, coal tar, floor oil, foam raw materials and additives. It is an ideal conveying and pressurizing equipment in the glass, foam, building materials, chemical construction, petroleum, and grain and oil industries.
Flow Rate: 1-150m3/h (16.7-2500L/min)
Discharge Pressure: 0.6/1.0/1.6Mpa
Power: 1.5-75kW
Product Description
Summarize:


2CG high temperature gear pump is composed of gears, shafts, pump body, pump cover, shaft end seals and other parts. All parts are made of suitable temperature-resistant materials. The running parts in the pump are all lubricated by the medium it transports. The 2CG type high temperature gear pump is equipped with a safety valve to prevent damage to the pump and motor due to overload.

Generally used in:
It is suitable for conveying non-solid particles and fibers, non-corrosive high temperature liquid, the medium temperature can reach 250oC, and the viscosity is 5-1500cst.
It is used for conveying and pressurizing media such as residual oil, coal tar, floor oil, foam raw materials and additives. It is an ideal conveying and pressurizing equipment in the glass, foam, building materials, chemical construction, petroleum, and grain and oil industries
Advantage:
The pump has good self-priming, no need to pour liquid before starting the pump, simple and compact structure, easy to use and maintain. The pump automatically lubricates daily work by transporting liquid without additional lubricating oil. It uses an elastic shaft to transmit power, which can compensate for small deviations caused by installation and play a good buffering effect when subjected to hydraulic shocks.
Parameter Data:
Model Flow Capacity

Pressure
(Mpa)

Suction Height
(m)
Inlet/Outlet
(mm)
Power
(kW)
m3/h L/min
2CG-1 1 16.7 1.0 /1.6 5 Φ25 1.5
2CG-1.5 1.5 25 1.0/1.6 5 Φ25 1.5/2.2
2CG-2 2 33.3 1.0/1.6 5 Φ25 2.2/3
2CG-3 3 50 1.0/1.6 5 Φ25 3
2CG-5 5 83.3 1.0/1.6 5 Φ40 4
2CG-6 6 100 1.0/1.6 5 Φ40 4
2CG-7.5 7.5 125 1.0/1.6 5 Φ50 5.5
2CG-10 10 167 1.0/1.6 5 Φ50 5.5/7.5
2CG-12 12 200 1.0/1.6 5 Φ55 5.5/7.5
2CG-15 15 250 1.0/1.6 5 Φ55 7.5 /11
2CG-18 18 300 1.0/1.6 5 Φ55 7.5/11
2CG-18 18 300 1 4.5 Φ70 7.5
2CG-29 29 483.3 1 4.5 Φ70 11
2CG-38 38 633 1 4 Φ100 22
2CG-58 58 960 1 3.5 Φ100 30
2CG-72 72 1200 0.6 4 Φ150 37
2CG-96 96 1600 0.6 4 Φ150 45
2CG-112 112 1800 0.6 2.5 Φ200 55
2CG-150 150 2500 0.6 2.5 Φ200 75
