YCB Gear Lube Oil Pump
YCB Gear Lube Oil Pump
Circular Arc Gear Oil Pump YCB Series
The YCB series lube oil pump is a kind of gear oil pump, the gear teeth are in double arc shape, this design can make the machine gear surface wear less, rotate more smoothly and low noise.This machine applies to pumping non-corrosive lubricating-oil or equivalent liquid without solid particles and fibres at temperature below 200℃ and with the viscosity of 5-1500cSt. The YCB series gear pump provides an efficient, reliable and low maintenance solution to conveying jobs in industrial. Feel free to ask us about our machines!
Flow Rate: 0.6-97m3/h
Discharge Pressure: 0.6/1.6Mpa
Applications: For transferring oil
Product Description
Summarize:

YCB arc gear lube oil pump is suitable for conveying non-corrosive, no solid particles and fibers, the temperature is not higher than 200 ℃, viscosity of 5 × 10-6 ~ 1.5 × 10-3m2 / s (5-1500cSt) lubricating oil or other liquids similar to the nature of lubricating oil. If you need to transport 200-300 ℃ high temperature media or high viscosity media, need to change the process. The pump shaft end seal is designed in two forms, one is mechanical seal and the other is packing seal, which can be determined according to the specific use and user requirements.

Product Details:




Product Details:
1. It can give performance as transfer pump or booster in oil deliver system.
2. It can be also applied as fuel pump for delivery system, pressurization and injection in fuel supply system.
3. It can be also hydraulic pump supplying hydraulic power in hydraulic system;
4. In all industry fields it can be as lubricating pump.

Advantage:
1. The circular arc design of this machine allows for smooth and efficient oil delivery to improve overall productivity.
2. With the YCB type gear pump of compact construction and durable materials, which reduces downtime and maintenance costs throughout the life of the unit.
3. The pumps are use reliable materials and precision technology to ensure the high performance of the machine even under harsh working conditions.
4. They are bi-rotational so the discharge end can be changed.



Performance Data:
Model Flow
(m3/h)
Pressure
(Mpa)
Rev
(rpm)
Npshr
(m)
Frequency
(hz)
YCB0.6-0.6 0.6
1.0
0.7
1.2
0.6 910
1390
1130
1710
5.5 50
50
60
60
YCB0.6-1.6 0.6
1.0
0.7
1.2
1.6 910
1400
1130
1710
7.0 50
50
60
60
YCB1.6-0.6 1.6
2.5
1.9
3.0
0.6 910
1400
1130
1710
5.5 50
50
60
60
YCB1.6-1.6 1.6
2.5
1.9
3.0
1.6 940
1440
1150
1750
7.0 50
50
60
60
YCB3.3-0.6 3.3
5.0
4.0
6.0
0.6 940
1420
1150
1730
5.0 50
50
60
60
YCB3.3-1.6 3.3
5.0
4.0
6.0
1.6 960
1440
1170
1750
7.0 50
50
60
60
YCB4-0.6 4.0
6.0
4.8
7.2
0.6 940
1420
1150
1730


5.0 50
50
60
60
YCB4-1.6 4.0
6.0
4.8
7.2
1.6 960
1440
1170
1750
7.0 50
50
60
60
YCB8-0.6 8.0
12.0
9.6
14.4
0.6 960
1440
1170
1750
5.0 50
50
60
60
YCB8-1.6 8.0
12.0
9.6
14.4
1.6 970
1460
1170
1760
7.0 50
50
60
60
YCB10-0.6 10.0
15.0
12.0
18.0
0.6 960
1440
1170
1750
5.0 50
50
60
60
YCB10-1.6 10.0
15.0
12.0
18.0
1.6 970
1470
1170
1770
7.0 50
50
60
60
