CBN Series Hydraulic Gear Pump
CBN series hydraulic gear pump adopts a bridge-type external belt pulley and direct-connect motor design, which is suitable for handling different viscous liquids. It is widely used in mining, chemical, construction, transportation, industrial automation, agriculture and other fields because of its features of low noise, large suction force, compact structure, high performance and stable operation.
Power: 1.5-22kW
Flow Rate: 4-60m3/h
Discharge Pressure: 0.4/0.6/0.75Mpa
Product Description
Summarize:

CBN series hydraulic gear pump is a power element in the hydraulic system, widely used in automobiles, lifting and transportation machinery, construction machinery, mining machinery, agricultural machinery, light industrial machinery, etc. This machine is equipped with bridge-type external belt wheel drive and motor direct-connection method, which is characterized by low rotational speed, large suction range and high efficiency. Meanwhile, in order to also be used in food, beverage, daily chemical and pharmaceutical and other industries, this machine all made of durable stainless steel acid-proof and anti-corrosion material.


Product Details:
CBN series gear pumps are composed of pump body, pump cover, gears, shaft end seal and other main parts. This product adopts bridge type external mounted pulley transmission direction and motor direct connection direction, and the seal adopts two structures such as mechanical seal and imported packing seal, and the seal can be selected according to the conveyed liquid.





Application:
 It is appropriate for all kinds of viscous liquids, and can be used under the condition of temperature lower than 230℃ and viscosity about 2000m2/s. It can transport paint, rosin, paraffin, soap, sewage sludge, asphalt, high-viscosity oil, butter, syrup, sauce products, grease, toothpaste, pharmaceutical raw materials and a variety of liquid paste products.

Feature:
1. It has high volumetric efficiency, which can effectively reduce energy loss.
2. This product can meet the pressure requirements of different hydraulic systems.
3. The noise level of this product is low, generally below 70dB(A), which can be applied to the working environment with high requirements on noise.


Performance Data:
Model Port(mm) Flow(m3/h) L/min Pressure(Mpa) Speed(r/min) Motor Power(w)
CBN -4 32 4 66 0.75 960 1.5
CBN -7 40 7 116 0.75 960 3
CBN -13 50 13 216 0.75 960 5.5
CBN -18 70 18 300 0.6 960 7.5
CBN -30 80 30 500 0.6 960 11
CBN -45 100 45 750 0.6 960 15
CBN -60 100 60 1000 0.4 960 22
