Product Description

Summarize:

IH series stainless steel centrifugal pump is a single stage single suction chemical centrifugal pump, which is suitable for conveying corrosive liquids without solid particles and with viscosity similar to water. This machine has become indispensable conveying equipment in chemical, petroleum, pharmaceutical, metallurgy, electric power and other industries due to their high efficiency, reliable sealing performance, corrosion resistance, high mechanical strength, reasonable structure and other advantages.

Product Details:

IH series stainless steel centrifugal pumps are mainly composed of vane drive system, sealing nut, pump cover, impeller, intermediate bracket, seals, suspension parts, shaft and so on. The pump cover is clamped in the middle by the connector on the middle fixed bracket, and then through the connection between the pump body and the middle bracket. The pump body is designed as axial suction, radial discharge, foot bearing type, which can be directly fixed on the base. At the same time, the suspension parts are supported on the base with the suspension bracket through the connector on the intermediate fixed bracket. The pump is equipped with an extended coupling, in other words, the inlet and outlet connection lines, pump body and motor can be maintained without disassembly.

Application:

1. Metallurgical Industry: For smelting, slurry transportation, etc.
2. Oil and Gas Industry: Used for oil field water injection, oil refining, etc.
3. Electric Power Industry: Used for conveying cooling water, chemicals, etc.
4. Chemical Industry: Conveying acid and alkali liquids, salt solutions, organic solvents, etc.
5. Pharmaceutical and Food Industry: This machine applies to convey chemicals, dairy products, fruit juice, etc.
6. Environmental Protection Industry: It is suitable for handling sewage treatment, waste gas desulfurization, etc.

Feature:

1. High efficiency and energy saving: The efficiency of IH series stainless steel centrifugal pump is increased by 3% to 5% on average compared with traditional F-type pump, which is an ideal energy-saving product.
2. Excellent corrosion resistance: The pump body and key components are made of high-quality corrosion-resistant materials, such as stainless steel, alloy steel, etc., which can effectively resist the erosion of acid and alkali liquids.
3. High-temperature and pressure resistance: This machine has excellent high-temperature and pressure resistance, suitable for high temperature, high pressure and other complex working conditions.
4. Reliable sealing performance: The shaft seal adopts packing or mechanical sealing, and the two kinds of sealing pump cover can be common.

Performance Data:

Model	Speed	Flow (m3/h)	Flow (L/S)	Head (m)	Power
					Medium Density
					1.0	1.35	1.85
IH50-32-125	2900	12.5	3.47	20	2.2	6.0	4.0
IH50-32-125	1450	6.3	1.74	5.0	0.55	0.55	0.55
IH50-32-160	2900	12.5	3.47	32	3.0	4.0	5.5
IH50-32-160	1450	6.3	1.74	8.0	0.55	0.75	1.1
IH50-32-200	2900	12.5	3.47	50	5.5	7.5	11
IH50-32-200	1450	6.3	1.74	12.5	1.1	1.1	1.5
IH50-32-250	2900	12.5	3.47	80	11	15	18.5
IH50-32-250	1450	6.3	1.74	20	2.2	2.2	3.0
IH65-50-125	2900	25	1.53	2.0	3.0	4.0	5.5
IH65-50-125	1450	12.5	6.94	5.0	0.55	0.55	0.75
IH65-50-160	2900	25	2.78	32	5.5	7.5	11
IH65-50-160	1450	12.5	6.94	8.0	0.75	1.1	1.5
IH65-40-200	2900	25	2.92	50	11	11	15
IH65-40-200	1450	12.5	6.94	12.5	1.5	2.2	2.2
IH65-40-250	2900	25	2.92	80	15	3.0	30
IH65-40-250	1450	12.5	6.94	20	2.2	37	4.0
IH65-40-315	2900	25	3.06	125	30	5.5	55
IH65-40-315	1450	12.5	6.94	32.0	5.5	5.5	7.5
IH80-65-125	2900	50	13.9	20	5.5	7.5	11
IH80-65-125	1450	25	6.94	5.0	0.75	1.1	1.5
IH80-65-160	2900	50	13.9	32	11	11	15
IH80-65-160	1450	25	6.94	8.0	1.5	1.5	2.2
IH80-50-200	2900	50	13.9	50	15	18.5	30
IH80-50-200	1450	25	6.94	12.5	1.1	1.5	2.2
IH80-50-250	2900	50	13.9	80	30	37	45
IH80-50-250	1450	25	6.94	20	4.0	5.5	7.5
IH80-50-315	2900	50	13.9	125	45	55	75
IH80-50-315	1450	25	6.94	32	7.5	7.5	11
IH100-80-125	2900	100	27.8	20	11	15	18.5
IH100-80-125	1450	50	13.9	5.0	1.5	2.2	3.0
IH100-80-160	2900	100	27.8	32	15	22	30
IH100-80-160	1450	50	13.9	8.0	2.2	3.0	4.0
IH100-65-200	2900	100	27.8	50	30	37	45
IH100-65-200	1450	50	13.9	12.5	3.0	4.0	5.5
IH100-65-250	2900	100	27.8	80	45	55	75
IH100-65-250	1450	50	13.9	20	5.5	7.5	11
IH100-65-315	2900	100	55.6	125	75	90	132
IH100-65-315	1450	50	27.8	32	11	15	18.5
IH125-100-200	2900	200	55.6	50	45	55	90
IH125-100-200	1450	100	27.8	12.5	7.5	11	15
IH125-100-250	2900	200	55.6	80	11	110	132
IH125-100-250	1450	100	27.8	20	132	15	18.5
IH125-100-315	2900	200	55.6	125	18.5	160	220
IH125-100-315	1450	100	27.8	32	18.5	22	30
IH125-100-400	1450	100	27.8	50	18.5	30	37
IH50-125-250	1450	200	55.6	20	30	30	37
IH50-125-315	1450	200	55.6	32	30	37	55
IH50-125-400	1450	200	55.6	50	55	75	90
IH200-150-250	1450	400	111.1	20	37	55	75
IH200-150-315	1450	400	111	32	55	75	110
IH200-150-400	1450	400	111	50	90	132	160
