Product Description

Summarize:

CYZ series self priming centrifugal pumps are not only suitable for tank trucks, the petroleum industry, and land-based oil depots, but can also be used as marine cargo oil pumps, fire pumps, ballast pumps, and bilge pumps. This pump is constructed using durable materials and hard alloy mechanical seals, ensuring reliable and stable operation when transporting petroleum products such as kerosene, diesel, aviation fuel, and gasoline, as well as water and seawater. Additionally, the pump has strong self-priming capability, eliminating the need for a foot valve in the pipeline. In other words, it can operate as long as there is a sufficient quantity of priming oil stored within the pump housing.

Application:

CYZ series self priming centrifugal pumps is capable of transporting petroleum products such as gasoline, diesel, kerosene, and jet fuel, as well as handling media such as seawater and freshwater. As a result, this pump can be widely applied in industries such as chemicals, petroleum, land-based oil storage facilities, and oil tankers, and can also serve as shipboard cargo oil pumps, bilge pumps, fire pumps, and ballast pumps.

Feature:

1. The pump is made of high-quality materials and features carbide mechanical seals, ensuring a long service life.
2. The rear door structure allows for quick maintenance and servicing by simply removing the corresponding parts to disassemble the impeller and replace the seals.
3. The discharge piping does not require a safety valve, and the suction piping does not require a foot valve, resulting in a simplified piping system and improved operating conditions.

Performance Data:

Model	Q (m³/h)	H (m)	Shaft Power	Efficiency (%)	Rev r/min		Motor
Model	Q (m³/h)	H (m)	Shaft Power	Efficiency (%)	Rev r/min		Power( kw)
20-20-100	1	20	0.09	26		2800	0.75
20-20-125	1.5	22	0.22	30		2800	0.75
25-25-160	3	27	0.53	30		2900	1.5
32-32-160	6	28	0.85	50		2900	1.5
32-32-200	6	50	2.37	45		2900	3.0
40-25-160	10	28	1.72	45		2900	2.2
50-32-160	12.5	30	1.90	57		2900	3
50-32-200	12.5	50	3.78	45		2900	5.5
50-32-200	18	40	3.95	50		2900	5.5
50-32-200A	16	32	3.35	42		2900	4
50-32-250	12.5	80	6.2	44		2900	11
50-32-250	18	70	7.6	45		2900	11
50-32-250A	16	60	6.2	42		2900	7.5
65-50-160	20	32	3.17	55		2900	5.5
65-40-200	25	50	5.87	58		2900	7.5
65-40-200	30	48	6.3	62		2900	7.5
65-40-200A	25	35	4.0	59		2900	5.5
65-40-250	25	80	10.3	53		2900	15
65-40-250A	20	51	5.67	49		2900	7.5
65-40-315	25	125	18.9	45		2900	30
65-40-315A	22.5	100	15.3	40		2900	22
80-50-200	40	52	8.85	64		2900	15
	50	50	9.7	70		2900	15
	60	46	11.0	70		2900	15
80-50-200A	45	40	7.8	63		2900	11
80-50-200B	40	32	6.37	55		2900	7.5
80-50-250	50	80	18.7	58		2900	22
80-50-250	60	72	19.6	60		2900	22
80-50-250A	43	60	12.8	55		2900	18.5
80-50-315	50	125	30.4	56		2900	37
80-50-315A	45	100	23.6	52		2900	30
100-65-200	80	53	16.5	70		2900	22
100-65-200	100	50	18.4	74		2900	22
100-65-200A	94	44	16.00	70		2900	22
100-65-200B	87	38	13.8	65		2900	15
100-65-200C	80	32	11.8	59		2900	15
100-65-250	80	85	28.9	64		2900	37
100-65-250	100	80	32.06	68		2900	37
100-65-250A	95	72	29.00	64		2900	37
100-65-250B	90	65	26.2	61		2900	30
100-65-315	80	130	45	63		2900	75
100-65-315	100	125	50.06	68		2900	75
100-65-315A	95	113	45.23	64		2900	55
125-100-200	200	50	35.40	77		2900	45
125-100-200A	178	40	26.60	73		2900	37
125-100-250	200	70	47.00	80		2900	55
125-100-250A	190	63	41.60	78		2900	55
150-150-200	350	50	60	80		2900	75
