SK Series Water Ring Vacuum Pump for Sale
SK Series Water Ring Vacuum Pump for Sale
SK Series Liquid Ring Vacuum Pump
SK series liquid ring vacuum pump is useful for pumping or pressurizing gases and other non-corrosive, water-insoluble, solid particle-free gases. This creates a vacuum or pressure in a closed vessel to meet the requirements of a particular process, including machinery, chemical, ceramics, petroleum, metallurgy, printing and dyeing, sugar and other industries.
Pumping Rate: 0.8-120m3/min
Vacuum Degree: -0.089~-0.097MPa
Water Consumption: 8-260L/min
Product Description
Summarize:


SK series vacuum pump is a kind of liquid ring vacuum pump, which is widely used in chemical, textile, metallurgy, sugar, pharmaceutical and other industries for pumping air and other non-corrosive, insoluble solid particles and a small amount of dust-containing gases. As the compression process of gas is isothermal in the working process, it is not easy to be dangerous when compressing and pumping flammable and explosive gases.

Product Details:
SK series liquid ring vacuum pumps compress gas by rotating a vane impeller inside a cylindrical housing. When a liquid is fed into the pump, under centrifugal acceleration, a cylindrical ring is formed that fits snugly inside the housing. This liquid ring creates a series of seals in the space between the impeller blades, thus forming the compression chamber. After the gas is drawn into the pump through the air inlet at the end of the casing, the gas is trapped in the compression chamber formed by the impeller blades and the liquid ring. Finally, the rotation of the impeller results in a volume reduction, which compresses the gas and discharges it into the discharge port at the end of the casing.
Application:
SK series water ring vacuum pumps are designed to pump or compress gases and other non-corrosive, water-insoluble gases without solid particles to form a vacuum or pressure in a closed container to meet the requirements of a specific process. And it can be widely used in machinery, petroleum, chemical, pharmaceutical, food, ceramics, sugar, printing and dyeing, metallurgy, environmental protection and electronics industries.
Feature:
1. It is capable of achieving large pumping rates in the rough vacuum range.
2. The product mainly uses water as the working medium and has low maintenance costs.
3. SK series liquid ring vacuum pumps have a compact design for easy installation and maintenance.
4. It can pump out all kinds of gases containing water vapor, flammable, explosive, small amount of dust and liquid.
Parameter Data:
Model Inspiratory
Volume
(m3/min)
Ultimate Vacuum Power
(kW)
Speed
(r.p.m)
Compressor
Pressure
(Mpa)
Inlet
(mm)
Outlet
(mm)
Water
Consumption
(L/min)
Max Vacuum Degree
is -450mmHg
mmHg MPa Vacuum Pump Compressor
SK-1.5 1.5 1.35 -680 -0.091 3 4 1450 0-1 70 70 10~15
SK-3 3 2.8 -710 -0.093 5.5 7.5 1450 0-1 70 70 15~20
SK-6 6 5.4 -710 -0.093 11 15 1450 0-1 80 80 20~30
SK-9 9 8.1 -710 -0.093 15 22 970 0-1 80 80 30~40
SK-12 12 11 -710 -0.093 18.5 30 970 0-1 80 80 40~50
SK-15 15 13.5 -710 -0.093 30 45 970 0-1 80 80 50~60
SK-20 20 18 -710 -0.093 37 55 740 0-1 150 150 60~80
SK-30 30 28 -710 -0.093 55 75 740 0-1 150 150 70~100
SK-42 42 37.2 -710 -0.093 75 - 740 - 150 150 95~130
SK-60 60 54 -710 -0.093 95 - 590 - 250 250 140~180
SK-85 85 76.5 -710 -0.093 132 - 590 - 250 250 180~220
SK-120 120 110 -710 -0.093 185 - 590 - 300 300 220~260
