Product Description

Summarize:

YCB series diesel oil gear pump is manufactured with a double arc sine curve tooth shape, compared with involute gears, its outstanding advantage is that there is no relative sliding of tooth profile surface during gear meshing. Therefore, there is no wear and tear on the tooth surface, smooth operation, no trapped liquid phenomenon, low noise, long life and high efficiency. Meanwhile, this machine gets rid of the traditional design, making the gear pump enter a new field in design, production and use.

Product Details:

Application:

1. YCB diesel oil gear pump can be used as transmission and pressurizing pump in oil transmission system.
2. It can be used as fuel pump for transmission, pressurization and injection in fuel system.
3. This machine can be as hydraulic pump to provide hydraulic power in hydraulic transmission system.
4. In all industrial fields, it can be used as lubricating oil pump.

Feature:

1. This pump is of the double-rotating type, so that the discharge end can be replaced.
2. The machine's rounded design allows for smooth and efficient oil delivery, thus increasing overall productivity
3. With compact construction and durable materials reduce downtime and maintenance costs throughout the life of the machine.
4. The use of reliable materials and sophisticated technology ensures high machine performance even under harsh operating conditions.

Performance Data:

Model	Flow (m3/h)	Presure (Mpa)	Rev (r/min)	Npshr (m)	Frequency (hz)
Model	Flow (m3/h)	Presure (Mpa)	Rev (r/min)	Npshr (m)	Frequency (hz)
YCB0.6-0.6	0.6	0.6	910	5.5	50
	1		1390		50
	0.7		1130		60
	1.2		1710		60
YCB0.6-1.6	0.6	1.6	910	7	50
	1		1400		50
	0.7		1130		60
	1.2		1710		60
YCB1.6-0.6	1.6	0.6	910	5.5	50
	2.5		1400		50
	1.9		1130		60
	3		1710		60
YCB1.6-1.6	1.6	1.6	940	7	50
	2.5		1440		50
	1.9		1150		60
	3		1750		60
YCB3.3-0.6	3.3	0.6	940	5	50
	5		1420		50
	4		1150		60
	6		1730		60
YCB3.3-1.6	3.3	1.6	960	7	50
	5		1440		50
	4		1170		60
	6		1750		60
YCB4-0.6	4	0.6	940	5	50
	6		1420		50
	4.8		1150		60
	6		1730		60
YCB4-1.6	4	1.6	960	7	50
	6		1440		50
	4.8		1170		60
	7.2		1750		60
YCB8-0.6	8	0.6	960	5	50
	12		1440		50
	9.6		1170		60
	14.4		1750		60
YCB8-1.6	8	1.6	970	7	50
	12		1460		50
	9.6		1170		60
	14.4		1760		60
YCB10-0.6	10	0.6	960	5	50
	15		1440		50
	12		1170		60
	18		1750		60
YCB10-1.6	10	.1.6	970	7	50
	15		1470		50
	12		1170		60
	18		1770		60
