SHHLB gear pumps are mainly used in the petroleum, chemical, construction, food processing, and biopharmaceutical industries to handle liquid media of various properties and viscosities. To effectively reduce internal leakage, the gears are manufactured using high-precision machining processes and have been optimally designed to enhance volumetric efficiency and extend the equipment’s service life. Its compact design, smooth operation, and ease of maintenance enable this equipment to meet the diverse requirements for continuous, metered, and process-specific fluid transfer in various industrial production processes.
Product Details:
SHHLB high-viscosity gear pump consists primarily of a rotor, shaft, pump body, front cover, bracket, seals, and other major components. When the motor drives the pump shaft to rotate, the inner rotor drives the outer rotor in the same direction, gradually expanding the enclosed volume to create a local vacuum and rapidly drawing the medium into the pump chamber. Through continuous rotation of the rotors, the liquid medium is squeezed and continuously discharged, thereby ensuring stable delivery. This operating mechanism effectively reduces shear forces and minimizes wear between components, thereby extending the equipment's service life.
Application:
SHHLB gear pumps are well-suited for fluids that are lubricating and do not contain large amounts of hard particles or long fibers. For example, they can efficiently and reliably pump media such as asphalt, high-viscosity resins, fuel oil, heavy oil, syrup, and vegetable oil. As a result, they are widely used in industries such as petroleum, chemicals, road construction, and food processing.
Feature:
1. This product series is compatible with a wide range of media and can efficiently transport substances ranging from asphalt to honey.
2. The pump utilizes high-precision machining processes to effectively reduce internal leakage and improve volumetric efficiency.
3. It operates with uniform flow and minimal pressure fluctuations, reducing the impact on piping systems and downstream process equipment.
4. The pump can be optionally equipped with a thermal insulation jacket to meet the temperature control requirements for media prone to solidification or high viscosity during conveyance, based on the characteristics of the media and operating conditions.
