KCB series gear pumps are suitable for conveying non-corrosive lubricants such as crude oil, diesel, and lubricating oil with temperatures below 300°C and viscosities ranging from 5 to 1500 cst. Consequently, this equipment plays a critical role in industrial fluid transfer across sectors including chemical, petroleum, building materials, and hardware. To effectively reduce energy consumption during the conveying process, the equipment employs advanced gear design and precision manufacturing techniques, significantly enhancing overall conveying efficiency and extending its service life.
Product Details:
KCB series gear oil pump primarily consists of gears, shafts, pump body, valves, and shaft end seals. During operation, internal components are automatically lubricated by the pumped medium. To minimize torque during gear operation, the pump incorporates optimally designed discharge and return oil grooves. Additionally, it features a safety valve for overload protection, with a full return oil pressure set at 1.5 times the pump's rated discharge pressure.
Application:
1. Lubricating Oil System: For circulating and conveying lubricating oil in mechanical equipment.
2. Chemical Industry: Conveying non-corrosive, particle-free chemical liquids.
3. Marine Systems: Used as marine fuel supply pumps or lubrication pumps.
4. Fuel Transfer: Conveying low-viscosity fuels such as diesel and heavy oil.
Feature:
1. This pump reduces pressure fluctuations, enabling smoother medium delivery while effectively minimizing pipeline vibration and noise.
2. Featuring a removable rear cover design, maintenance of gears and bearings can be performed without disassembling pipelines, minimizing downtime.
3. The equipment utilizes high-precision heat-treated reinforced gears with wear-resistant tooth surfaces, ensuring long-term stable meshing and achieving volumetric efficiency exceeding 85%.
Performance Data:
| Model |
Capacity |
Speed |
Exhaust Pressure |
Motor |
| m³/h |
l/min |
r/min |
Mpa |
Power Kw |
| KCB-18.3 |
1.1 |
18.3 |
1400 |
1.45 |
1.5 |
| KCB-33.3 |
2 |
33.3 |
1420 |
1.45 |
2.2 |
| KCB-55 |
3.3 |
55 |
1400 |
0.33 |
1.5 |
| KCB-83.3 |
5 |
83.3 |
1420 |
0.33 |
2.2 |
| KCB-135 |
8 |
135 |
940 |
0.33 |
2.2 |
| KCB-200 |
12 |
200 |
1440 |
0.33 |
4 |
| KCB-300 |
18 |
300 |
960 |
0.36 |
5.5 |
| KCB-483.3 |
29 |
483.3 |
1440 |
0.36 |
7.5 |
| KCB-633 |
38 |
633 |
970 |
0.28 |
11 |
| KCB-960 |
58 |
960 |
1470 |
0.28 |
11 |
| KCB-1200 |
72 |
1200 |
740 |
0.6 |
37 |
| KCB-1600 |
96 |
1600 |
980 |
45 |
| KCB-1800 |
110 |
1800 |
740 |
0.6 |
55 |
| KCB-2500 |
150 |
2500 |
985 |
75 |
| KCB-2850 |
170 |
2850 |
740 |
0.6 |
90 |
| KCB-3800 |
230 |
3800 |
989 |
110 |
| KCB-4100 |
245 |
4100 |
743 |
0.6 |
132 |
| KCB-5400 |
325 |
5400 |
989 |
160 |
| KCB-5600 |
330 |
5600 |
744 |
0.6 |
160 |
| KCB-7600 |
460 |
7600 |
989 |
200 |
| KCB-7000 |
420 |
7000 |
744 |
0.6 |
185 |
| KCB-9600 |
570 |
9600 |
989 |
250 |
| KCB-13000 |
800 |
13000 |
490 |
0.6 |
315 |
