Product Description

Summarize:

Fully automatic water bottle filling machine is the main machine for filling in liquid production line, which is mainly used for filling, capping and sealing of glass bottles or plastic bottles. It is able to be applied to handle mineral water, beverage, milk, honey, olive oil, hand sanitizer and other liquids filling, can also be applied to food, pharmaceutical, chemical, daily chemical and other fields.

Product Details:

It has high degree of automation and precise filling measurement, and is suitable for quantitative filling of non-gas-containing liquor, beverage, condiment and other solutions in different shapes of bottles such as plastic bottles, glass bottles and so on. Moreover, the whole machine adopts plc intelligent control, which is characterized by specific no bottle no filling, fast filling speed, high precision and no liquid spillage.

Application:

It is widely used in cosmetics, food, medicine, daily chemical industry, applicable materials in a variety of creams, laundry detergent, shampoo, shower gel, mineral water, milk, beverages, semi-fluid, honey, and a variety of viscous body of the material filling.

Feature:

1. The bottle sizes can be changed very quickly and easily.
2. Servo-driven submersible nozzles are used for bottom-up filling.
3. The inert gas purge station for use in conjunction with an aerator.
4. It is available with standard conveyor belts or chucks for unstable bottles.
5. Docking filling station models available for quick change of wetting paths.
6. Bottle indexing possible by installing a conveyor belt in the filling machine.

Performance Data:

Model	RCGF14-12-5	RCGF16-16-5	RCGF24-24-8	RCGF32-32-8	RCGF40-40-12	RGF60-60-15
Capacity(for 500ml)	2000BPH	4000BPH	8000-10000BPH	12000-15000BPH	16000-18000BPH	24000BPH
Suitable Bottle Shapes	circular or square
Bottle Diameter(mm)	Dia50-Dia115mm
Bottle Height (mm)	160-320mm
Filling Type	Overflow filinig type /Hot filling
Function	Rinsing filling capping
Rinsing Pressure	>0.06Mpa <0.2Mpa
Application	Juice / Tea drinks / Milk Beverage
Total Power (KW)	4.4kw	4.4kw	4.4kw	5.2kw	6.2kw	7.8kw
Overall Dimensions	2.3*1.9m	2.5*1.9m	2.8*2.15m	3.1*2.5m	3.8*2.8m	4.5*3.3m
Height	2.3m	2.5m	2.5m	2.5m	2.5m	2.6m
Weight(kg)	3500kg	5200kg	7000kg	9500kg	10500kg	12000kg
