Summarize:
.jpg)
Automatic bottle juice filling machine is ideal for precise and fast filling of thin to medium viscosity liquids as it has an automated body integrating water treatment, cleaning, filling, labeling and capping. It has a complete temperature control system, automatic cleaning system, precise filling control system, etc., so it can ensure the accuracy, consistency and hygiene of filling. In addition, if you need, we can provide complete solutions for fruit juice, tea drink and energy drink filling lines, including water treatment systems, syrup melting systems, mixing and blending systems, homogenizers and sterilizing systems, dosage systems, cleaning and filling, capping machines, coding machines, automatic labeling machines, automatic packaging machines, automatic palletizing systems, and so on.
Product Details:
When using a fully automatic bottle filling machine, bottles, cans and containers to be filled need to be placed under the filling nozzle either manually or automatically using a conveyor belt. Once the sensors of the filling machine recognize the container, the valve of the filling nozzle will open and a steady stream of liquid will flow out. The machine will utilize the volume and weight functions to determine if the container is full, and if it is, the system will automatically close the valve and stop the flow, thus completing the filling.
.png)
Application:
It can be applied in many industries such as biochemical, food, automotive supplies, daily chemicals, pharmaceuticals, etc. The filling liquids also include pesticides, veterinary drugs, nutrient solutions, edible oils, honey, beverages, fruit juices, glass water, antifreeze, lubricants, detergents, laundry detergents, mouthwash, medicinal liquids, and many other types of liquids.
Feature:
1. The product has high accuracy of filling level control.
2. This machine has a large filling range and adjustable filling volume.
3. It is simple to operate, easy to clean and repair, low maintenance cost.
4. The filling head designed and developed by ourselves can effectively prevent dripping.
5. The main seals are made of silicone and the main parts are made of 304 or 316 stainless steel.
6. The filling time adjustment adopts actual measurement correction method and is controlled by digital display.
Performance Data:
| Model |
SGF12125 |
SGF18186 |
SGF24248 |
SGF323210 |
SGF404012 |
SGF505012 |
| Washing/Filling/Capping Heads |
12-12-5 |
18-18-6 |
24-24-8 |
32-32-10 |
40-40-12 |
50-50-12 |
| Production Capacity (B/H) |
2000-4000 |
5000-7000 |
8000-12000 |
12000-15000 |
16000-20000 |
20000-24000 |
| Motor Power(kw) |
2.2kw |
2.2kw |
3kw |
5.5kw |
7.5kw |
11kw |
| Weight (kg) |
2500 |
3500 |
4500 |
6500 |
8500 |
9800 |
