Product Description

Summarize:

Sanitary Centrifugal Pump is composed of motor, pump shaft, mechanical clamping jacket, sanitary mechancial seal, connection support, rear plate cover, impeller, pump shell, etc. It has large internal round chamfer and cleaning type seal. It has the stainless steel protection cover used for protecting the motor, and the equipment is supported by four adjustale feet.

Generally Used In:

Applicable to the fields of food, dairy, beverage, drink, pharmacy, cosmetic etc industry.
1. Chemical Industry: Fat, Dissolvent, Resin, Paint, Pigment, Oil Agent etc.
2. Food Industry: Yogurt, Ice Cream, Cheese, Soft Drink, Fruit Jelly, Ketchup, Oil, Syrup, Chocolate etc.
3. Daily Chemicals: Facial Foam, Hair Gel, Hair Dyes, Toothpaste, Shampoo,Shoe Polish etc.
4. Pharmacy: Nutrition Liquid, Chinese Traditional Patent Medicine, Biological Products etc.

Advantage:

1. Sanitary centrifugal pump impeller direct motor spindle, unique design, easy installation, high precision to ensure concentricity, solve the vibration, not only improve the strength of the pump, and avoid the traditional impeller and shaft complex assembly. Precise clearance for optimal performance.
2. Sanitary centrifugal pump has excellent performance, reasonable structure, small volume and reliable use.
3. Centrifugal pump impeller structure enables the pump to achieve high head at low flow.
4. Centrifugal pump has the advantages of high efficiency and energy saving, no dead Angle and easy cleaning.
5. Sanitary centrifugal pump cover and impeller are all made of high quality stainless steel SS304/SS316L, fully in line with GMP requirements.

Installation:

Installation Method and Place:
1.The drive is in good condition.
2.Whether the on-site power supply is the same as the rated power on the motor nameplate.
3.Whether it meets the environmental conditions (avoid flammable and explosive environment or acid corrosion environment).

Installation Location:
The installation foundation of the pump should generally be level and sufficient-strengthened ground. Install it as far as possible on the lowest position of the equipment, that is, at the position with the maximum head height.

Piping Installation:
The diameter of pump, pipe and the inlet and outlet of the pump should be the same, and the diameter of the inlet pipe should not be too small. When the diameter of the pipe is smaller than the diameter of the pump, adjust it with an eccentric reducer to shorten the diameter of the pipe so as to avoid formation of a gas leak. The outlet pipe diameter must not be too large either. When the outlet pipe diameter is larger than the pump outlet, try to extend it. Distance from the pump outlet to avoid overloading the pump motor.

Performance Data:

Model	Flow (t/h)	Lift (m)	Power (kW)	Inlet/Outlet (mm)
SCP-1.5-14	1.5	14	0.55	38/32
SCP-3-16	3	16	0.75	38/38
SCP-5-16	5	16	1.1	38/38
SCP-3-24	3	24	1.5	51/38
SCP-3-30	3	30	2.2	51/38
SCP-5-24	5	24	1.5	51/38
SCP-5-30	5	30	2.2	51/38
SCP-10-24	10	24	2.2	51/38
SCP-10-36	10	36	3	51/38
SCP-15-24	15	24	3	51/51
SCP-20-24	20	24	3	51/51
SCP-20-36	20	36	5.5	51/51
SCP-20-60	20	60	11	63/51
SCP-25-35	25	35	5.5	51/51
SCP-30-24	30	24	5.5	63/51
SCP-30-36	30	36	7.5	63/51
SCP-30-50	30	50	11	63/63
SCP-30-60	30	60	15	73/51
SCP-40-24	40	24	7.5	63/51
SCP-40-35	40	35	11	63/63
SCP-40-50	40	50	15	73/63
SCP-50-50	60	50	18.5	76/63
SCP-60-30	50	30	15	73/63
SCP-80-50	80	50	22	89/76
