Small Sacue Packing Machine
Small Sacue Packing Machine
Sauce Sachet Packing Machine
Vertical sauce sachet packing machine is an excellent choice for packaging liquids, sauces, soups, edible oils, creams, honeys and shower gels, and it can easily meet customers' bar packaging application needs. It is characterized by simple operation, easy maintenance, compact structure, complete functions, small footprint and strong applicability.
Filling Size: 0.1-50ml
Filling Speed: 10-30 bag/min
Email: sales@shenghuipump.com
Product Description
Summarize:

Automatic sauce packing machine is often used for packaging all types of poor liquidity sauce packaging, equipped with three-side seal or four-side seal bag molding and precise positioning sealing and cutting system, which can be adjusted through the piston stroke method to achieve precise control of the flow rate, automatic metering and automatic filling purposes. Suitable for viscous body, suspension and emulsion oil and other poor fluidity of semi-fluid paste material filling device. Widely used in food, medicine, consumer goods the chemical industry and other fully automatic packaging.
Product Details:


Application:
It is adaptable for filling viscous body, suspension and emulsion oil and other poor fluidity of semi-fluid paste material filling device. Widely used in food, medicine, consumer goods and chemical industry and other fully automatic packaging.



Feature:
1. The sealing forms include three-side seal, four-side seal and back seal.
2. Adopting screw to cut materials, easy to measure.
3. It can automatically complete the steps of bag making, measuring, discharging, sealing, cutting, counting, etc., and can be configured to print the batch number according to customers' requirements.
4. Adopting advanced microcomputer controller to drive the stepping motor to control the length of bag making, with stable performance, convenient adjustment and accurate detection. Choose intelligent temperature controller, PID regulation, to ensure that the temperature error range is controlled within 1 ℃.


Performance Data:
Specifications Dimensions of bag Speed of packing Material for packing
Three side sealing powder packing machine 50-150*10-150mm 30-60bpm Composite material
Four side sealing powder packing machine 50-150*10-150mm 30-60bpm
Back seal right Angle powder packing machine 20-150*10-140mm 30-61bpm
Back seal round corner powder packing machine 20-150*10-140mm 30-64bpm
Three side sealing round corner packing machine 20-150*10-150mm 30-62bpm
Powder packing machine 20-150*10-140mm 30-63bpm
Powder bag packing machine 20-150*10-140mm 30-65bpm
