Rotor pump is also called colloid pump, cam pump, three-vane pump, universal pump and so on. Rotor pump belongs to volumetric pump. It achieves the purpose of conveying fluid by means of the periodic conversion of several fixed volume conveying units in the working cavity. The mechanical energy of the motor is directly converted into the pressure energy for conveying fluid through the pump, and the flow rate of the pump only depends on the change of the volume of the working cavity and its frequency in the unit time, and has nothing to do with the discharge pressure; the rotor pump actually works through a pair of synchronous rotors. The rotor is driven by a pair of synchronous gears in the box, and the rotor rotates synchronously in the opposite direction driven by the main shaft and auxiliary shaft. The volume of the pump is changed, thus forming a higher vacuum and discharge pressure. It is especially suitable for the transportation of sanitary medium and corrosive and high viscosity medium.
1. All the spare parts in the stainless steel cam rotor pump that are in contact with the conveying materials are made of stainless steel materials that meet the sanitary standards, and the seals are made of non-toxic rubber. Reliable anti-rust and non-toxic sealing ensure safety and health.
2. The streamline structure of the rotor and the absence of dead points and non-metallic parts in the rotor chamber avoid pollution to the transported material.
3. Suitable for on-site CIP cleaning and steam disinfection, in full compliance with the requirements of American FDA code and pharmaceutical grade (GMP) specification.
4. It is especially suitable for foaming and conveying media with high viscosity, high concentration and any particles in the process of re-transportation. the materials transported by them keep the original quality change without any physical and chemical reaction.
5. The use of external dynamic, static ring mechanical seal, can be washed directly with water, high pressure resistance, not easy to wear, no leakage.
6. Small volume, large flow, high head pressure, suitable for long distance and high resistance quantitative transportation.
7. The impeller of stainless steel cam rotor pump is separated from the transmission gear, and there is a certain gap between the spare parts in the pump cavity, no contact with each other, no wear, low noise, good reliability, long service life, energy saving and consumption reduction.
8. After configuring the frequency converter, the flow can be adjusted at will, and can be used as a general metering pump.
9. Can transport steam, liquid, solid and other three-phase mixed materials. The viscosity of the transportable medium can be high 1000000CP and the slurry with solid content up to 55%.
10. The stainless steel cam rotor pump has the advantages of compact structure, convenient maintenance, almost no vulnerable parts and low operating cost.
